Install Manual

This bundle includes the Eccotemp EL22i Indoor Natural Gas Tankless Water Heater and the 4" Horizontal Z-Vent Water Heater Vent Kit with Backflow Preventer.

The Eccotemp EL22i Natural Gas Tankless Water Heater is the largest indoor model of the Eccotemp tankless line. This model has a sleek, black tempered front glass casing with automatic temperature controls and a touch screen with an LED digital display that shows the output temperature reading and gallons per minute flow rate. The Eccotemp EL22i is rated at an impressive 6.8 gallons per minute and has a maximum BTU rate of 140,000. Whether you use natural gas or liquid propane the Eccotemp EL22i is the perfect solution for all the hot-water needs of a standard home or apartment with one or two bathrooms, as well as smaller commercial applications.



Product Features:

  • CSA Certified for US and Canadian use
  • Hot water capacity range: 0.8 - 6.8 GPM
    • 45-degree rise: 6.8 GPM
    • 50-degree rise: 5.0 GPM
    • 70-degree rise: 3.4 GPM
  • Digital Remote available for purchase separately
  • Natural Gas-Powered
  • 110-volt UL Listed Power Cord
  • Activation Flow: 0.8 GPM
  • Maximum Flow Rate: 6.8 GPM
  • Energy Factor: 0.80
  • Energy Rating: 82%
  • Minimum/Maximum Gas Rate: 26,000 - 140,000 BTUs
  • 4" Venting Required



The 4" Horizontal Stainless Steel Z-Vent Wall Hung Water Heater Vent Kit includes:

  • (1) Termination Hood
  • (1) 4" x 90 Degree Elbow
  • (1) 4" x 1' Pipe
  • (1) Wall Thimble
  • (1) 4" Universal Appliance Adapter with Back Flow Preventer

You will need to determine how many additional feet of venting you need and purchase an additional Z-Vent straight pipe. There is a maximum vent run of 20 feet, subtracting 4 feet for every 90 degree elbow in the run. This vent kit does not include a condensation drain pipe. If you need one, they are available for purchase separately.

EL22i Product Info and Manual
EL22i Warranty

The Eccotemp EL22i has been tested for use at elevations up to 2000 feet. Installation and use of the Eccotemp EL22i above 2000 feet may affect overall product efficiency and performance. Installation and use of the Eccotemp EL22i above 5000 feet is not recommended.

IMPORTANT NOTE: Cannot be used for HYDRONIC SYSTEMS, RECIRCULATING, or FLOOR HEATING.







Flow Rate 6.8 GPM
Color Black
Installation Indoor
Applications Standard Home, Apartment/Townhome
Power Type Natural Gas (NG)

17.75" x 29.50" x 9.50"
