How to Choose & Install a Sprinkler Pump (Sizing Guide + Step-by-Step)
How to Install a Sprinkler Pump
A properly sized sprinkler pump keeps pressure steady across zones and protects your irrigation investment. Use the quick sizing steps below, compare a few proven models, and follow the install checklist for a smooth first start.
Step 1 — Gather Your Numbers
- Flow (GPM): Add up the GPM of the sprinkler heads in your largest zone.
- Pressure at heads (PSI): Typical rotor/spray targets are ~40–60 PSI (check your nozzle charts).
- Suction lift (ft): Vertical distance from water surface to pump inlet (keep it as low as possible).
- Plumbing: Larger suction line (often 1.5") minimizes friction and helps priming.
- Power: Match voltage and amperage available (many pumps are dual-voltage 115/230V).
Compute TDH (Total Dynamic Head):
TDH ≈ (Desired PSI × 2.31) + suction lift (ft) + 10–15% for friction.
Pick a pump curve that delivers your zone’s GPM at that TDH (or slightly above).
TDH ≈ (Desired PSI × 2.31) + suction lift (ft) + 10–15% for friction.
Pick a pump curve that delivers your zone’s GPM at that TDH (or slightly above).
Quick Selector (Rule of Thumb)
| System Snapshot | What to Prioritize | Typical Class |
|---|---|---|
| Small–medium lawn, 1 large zone | GPM at ~45–55 PSI, easy priming | ~1 HP self-priming centrifugal |
| Medium–large lawn, multiple zones | Higher GPM at 50–60 PSI, cast-iron volute | ~1.5 HP self-priming centrifugal |
| Long runs or higher pressure needs | Stable pressure at higher TDH | ~2 HP self-priming centrifugal |
Model Highlights
Red Lion RL-SPRK100 — 1 HP Class
Red Lion RL-SPRK150 — 1.5 HP Class
Red Lion RL-SPRK200 — 2 HP Class
Step-by-Step: Install & First-Start
- Placement: Set the pump on a level, rigid pad as close to water level as practical to reduce suction lift.
- Suction plumbing: Use short, straight runs with minimal fittings. Upsize the suction line (often 1.5"). Add a foot valve/strainer at the intake and a quality check valve near the pump.
- Discharge line: Match your system pipe size. Add a union and ball valve for service.
- Prime: Fill the pump housing/volute completely via the priming port. Verify the suction line is airtight.
- Power & rotation: Wire per nameplate. On first energize, confirm smooth, quiet operation and correct pressure at the manifold.
- Pressure check: Open your largest zone and confirm target PSI at the heads. If low, re-check priming, suction leaks, or consider a model with more head.
- Protect: House the pump from weather with ventilation; ensure electrical connections are dry and GFCI protected.
- Seasonal: In freeze zones, drain the volute and lines before winter.
Troubleshooting Quick Wins
- Won’t prime: Refill volute, tighten fittings, shorten suction run, verify foot/check valve orientation.
- Low pressure: Check for suction air leaks, clogged strainer, undersized plumbing, or pick a model with higher head.
- Pulsing flow: Air entrainment on suction side—seal joints and ensure intake is fully submerged.
Tip: When you’re between sizes, choosing the next pump up often results in steadier pressure across zones—just be sure your plumbing and electrical supply match the selection.
