Sta-Rite SNC ProJet Series Cast Iron Shallow Well Jet Pumps 1/2Hp 115/230V

Sta-Rite SNC Series — Cast-Iron Shallow Well Jet Pump

The Sta-Rite SNC Series is a rugged, high-efficiency shallow well jet pump engineered for residential homes that need steady, reliable water pressure from clean, shallow well sources. Built from heavy-duty cast iron and designed for long service life, the SNC delivers dependable performance for everyday household water demands — from faucets and fixtures to irrigation and utility use.

Key Features & Benefits

• Heavy-duty cast-iron design for long life and reliable operation.
• Efficient shallow well performance for residential clean-water supply.
• Self-priming jet design for fast startups and smooth pressure delivery.
• High-strength impeller for dependable flow and consistent pressure.
• Fan-cooled motor supports continuous-duty operation.

Applications

• Residential water systems on shallow wells
• Household pressure boosting
• Garden and lawn irrigation
• Clean-water utility transfer

Specifications

Model Comparison

The Sta-Rite SNC Series offers dependable cast-iron durability and reliable shallow well performance, making it a solid choice for homeowners needing consistent water pressure from clean-water sources.

SPECIFICATIONS
Max. Liquid Temperature: 140°F
Max. Inlet Pressure: 50 PSI
Average Priming Time (min.) at 15’:
— SNC = 2.3; SND = 1.7
— SNE = 1.3; SNF = 1.1
Average Priming Time (min.) at 25’:
— SNC = 6.4; SND = 4.4
— SNE = 4.4; SNF = 2.6
Body: Close-grained cast iron
Nozzle: High-strength Lexan®
Venturi: Lexan
Impeller: Noryl®
Diffuser: Reinforced polypropylene
Shaft: One-piece threaded, 416 grade stainless steel
Base: Steel, 12 gauge
