Rain Bird RB15 15-Foot MPR Fixed-Pattern Spray Nozzles
Brand: Rain Bird | SKU: RB15F, RB15H, RB15Q
Product Overview
Choose a fixed spray pattern for lawn areas needing a 15-foot radius at 30 psi. Full-, half- and quarter-circle choices let you match the nozzle to an interior head, border or corner without using the same flow allowance for every pattern.
Key Features
- Three fixed arcs: 360°, 180° and 90°.
- The black top identifies the 15 Series.
- Adjustment screw controls radius and flow; arc stays fixed.
- Fits Rain Bird spray heads and shrub adapters.
Common Uses
- Replacing a matching fixed-pattern spray nozzle.
- Selecting an arc for lawn edges, corners or interior areas.
Technical Specifications
- Store SKUs: RB15F, RB15H, RB15Q
- At 30 psi: full-circle 3.70 gpm; half-circle 1.85 gpm; quarter-circle 0.92 gpm
- Operating pressure: 15–30 psi; optimum 30 psi
- Watering radius: 11 feet at 15 psi, 12 feet at 20 psi, 14 feet at 25 psi and 15 feet at 30 psi
- Trajectory: 30 degrees
- Top color: black
Compatibility & Installation Notes
Flush the spray body before fitting the nozzle and screen. Match the fixed arc to the head location, then check available pressure and zone flow. Rain Bird recommends no more than 25% radius reduction. Published performance assumes zero wind and testing on a 4-inch pop-up; coverage is not the nozzle's physical size. Spray body is purchased separately.
Frequently Asked Questions
Which RB15 option should I choose?
Choose RB15F for a full circle, RB15H for a half circle or RB15Q for a quarter circle.
Can I adjust the arc?
No. These are fixed-pattern nozzles; the screw adjusts radius and flow rather than changing the arc.
When does it reach 15 feet?
The published radius is 15 feet at 30 psi. Lower listed pressures produce a shorter throw.
Why Buy from Big Frog Supply?
Choose RB15 for a layout designed around a 15-foot radius at 30 psi. Full-, half- and quarter-circle options draw 3.70, 1.85 and 0.92 gpm respectively, so select both the coverage shape and the matching flow when sizing the zone. The black top helps identify the series during service.
