Rain Bird RB15 Strip-Pattern MPR Spray Nozzles
Brand: Rain Bird | SKU: RB15CST, RB15EST, RB15LCS, RB15RCS, RB15SST
Product Overview
Water narrow landscape strips with a pattern chosen for the head's position. Center-, end-, side- and left- or right-corner strip options cover different shapes; the 15 Series label does not mean every option waters the same rectangle.
Key Features
- Five fixed strip-pattern choices.
- Black top identifies the 15 Strip Series.
- Fits Rain Bird spray heads and shrub adapters.
Common Uses
- Narrow lawn strips beside walkways.
- Selecting coverage for the end, side, center or corner of a strip.
Technical Specifications
- All figures below are coverage width × length and flow at 30 psi
- RB15CST / 15CST: center strip; 4 × 30 feet; 1.21 gpm
- RB15EST / 15EST: end strip; 4 × 15 feet; 0.61 gpm
- RB15LCS / 15LCS: left corner strip; 4 × 15 feet; 0.49 gpm
- RB15RCS / 15RCS: right corner strip; 4 × 15 feet; 0.49 gpm
- RB15SST / 15SST: side strip; 4 × 30 feet; 1.21 gpm
- Operating pressure: 15–30 psi; optimum 30 psi
- Trajectory: 30 degrees
Compatibility & Installation Notes
Choose the pattern by head location and coverage shape, not by flow alone. Flush the body and install the nozzle and screen. Check coverage after installation; pressure and wind affect the watered area. Rain Bird advises against more than 25% radius reduction. A complete spray body is separate.
Frequently Asked Questions
Do all options water 4 × 15 feet?
No. At 30 psi, center and side strip options cover 4 × 30 feet; end and corner strip options cover 4 × 15 feet.
Are left and right corner options interchangeable?
No. Choose the left- or right-corner pattern that matches the required direction of coverage.
Can I use the center-strip flow for every variant?
No. At 30 psi the center and side options use 1.21 gpm, end strip 0.61 gpm and corner strip options 0.49 gpm.
