Spec Sheet   Install Manual

Add with the following Indoor Unit:

Haier AW12EH2VHD Arctic Series NG Highwall Indoor Unit 12000 BTU

HAIER AW12EH2VHD ARCTIC SERIES NG HIGHWALL INDOOR UNIT 12000 BTU

Provides amazing comfort in extremely cold climates.

For zones with exceptionally harsh winters, the Arctic Next Gen mini split AC with heat pump ensures you stay warm even when temps get down to -31 degrees F. Our Next Gen series also includes Smart Sensors that adjust temps when no one is in the room to save energy. Each unit is Energy Star rated with your choice of various indoor options for year-round efficient heating and cooling.

Features:

  • DC Inverters
  • Turbo Mode
  • Blue Fin
  • Quiet Mode
  • Easy to install
  • Easy PCB replacement

Cooling:

  • Rated Capacity BTU/hr: 11,500
  • Capacity Range BTU/hr: 3,100~13,600
  • Rated Power Input W: 910
  • SEER: 20
  • EER: 12.5
  • Moisture Removal Pt./h: 3.20

Heating:

  • Rated Heating Capacity BTU/hr: 12,500
  • Heating Capacity Range BTU/hr: 3,100~21,000
  • Rated Power Input W: 1,480
  • HSPF: 10.0
  • Max. Heating Capacity 5 degree F BTU/hr: 10,000

Operating Range:

  • Cooling °F(°C): 14~115(-10~46)
  • Heating °F(°C): -31~75(-35~24)

    Power Supply:

    • Voltage, Cycle, Phase V/Hz/-: 208/230-60-1

    Refrigerate Line:

    • Liquid O.D. in: 1/4
    • Suction O.D. in: 3/8 (Need to sue adaptor ship with ODU)
    • Factory Charge Oz: 62.1
    • Maximum Line Length Ft / m: 66/20
    • Maximum Height Ft / m: 50/15

    WiFi Connect RJ45 Newfi only
    Voltage/Hertz/Phase 208-230/60/1
    Temperature Range - Heating Mode -31-75 F (-35-24 C)
    Temperature Range - Cooling Mode 14-115 F (-10-46 C)
    System 12K Arctic
    Style Outdoor
    Series Arctic
    Rotary Compressor DC Inverter Driven Rotary
    Product Type Single Zone
    Outdoor Noise Level 54 dBA
    Model Type Outdoor
    Maximum Line Length (Ft/M) 33/10
    Maximum Height (Ft/m) 50/15
    Maximum Fuse Size A 20
    Factory Charge (ounces) 62.1
    Connections Flare
    Compatible Indoor Models AW12EH2VHD
    USYM12UCDSA
    USYF12UCDWA
    AB12SC2VHA
    Base Pan Heater Standard

    Package Quantity 1
    Overall Width 35 in
    Overall Height 27 1/2 in
    Overall Depth 13 7/8 in
    Net Weight 84.9
    Carton Width 39
    Carton Length 16.4
    Carton Height 30.4
    Approximate Shipping Weight 116.9
