Brand: Irritrol SKU: TC-6EX-R
Product Overview
The Irritrol TC-6EX-R Total Control-R is a six-station outdoor irrigation controller for residential, light-commercial, and larger landscape systems that need more programming flexibility than a basic three-program timer. It combines four independent programs, long station run times, multiple scheduling methods, and compatibility with optional Irritrol weather and remote-management accessories in a weather-resistant outdoor cabinet.
The controller provides 16 total start times assignable across the four programs, with station run times from 1 minute to 10 hours in one-minute increments. Seven-day, odd/even, and 1- to 30-day interval schedules help meet plant requirements and watering restrictions. Water budgeting adjusts program run times from 10% to 200% without rewriting each station, while non-volatile memory retains programmed data. The master-valve or pump-start circuit can be enabled or disabled by program, allowing some schedules to use a booster pump while others operate from standard supply pressure.
The six-station Total Control-R uses a 12-station terminal-board platform, allowing supported station-count changes through a compatible face-panel module. It is also compatible with optional Climate Logic weather sensing, SMRT Logic connected control, Irritrol RainSensor products, and CRR handheld remotes. Accessories and the 9-volt alkaline battery are sold separately.
Key Features
- Six-station outdoor irrigation controller
- Four independent programs
- 16 total start times assignable across programs
- Station run times from 1 minute to 10 hours
- Weekly, odd/even, and interval scheduling
- Water budgeting from 10% to 200%
- Non-volatile program memory
- Rain-sensor input with bypass
- Programmable master-valve or pump-start operation by program
- Electronic circuit protection
- Compatible with Climate Logic, SMRT Logic, and CRR accessories
Common Uses
- Residential properties with up to six active zones
- Light-commercial landscapes with complex schedules
- Systems requiring long drip or establishment run times
- Outdoor replacement of a compatible Total Control controller
- Installations that may later increase station capacity with a supported module
Compatibility and Installation Notes
This is the six-station outdoor model. Use compatible 24 VAC irrigation valve solenoids and follow Irritrol requirements for field wiring, grounding, sensors, and pump-start relays. Confirm compatible face-panel modules before planning any station-count increase. Climate Logic, SMRT Logic, CRR remotes, rain sensors, and the 9-volt battery are not included unless specifically stated.
Frequently Asked Questions
How many programs does TC-6EX-R provide?
It provides four independent programs with 16 total start times assignable across them.
Can it run a station longer than six hours?
Yes. Station run time can be programmed from 1 minute up to 10 hours.
Does it include app or internet control?
No. Optional SMRT Logic equipment is required for connected remote management.
Can the station count be increased?
The six-station model uses a 12-station terminal-board platform, but a compatible face-panel module is required. Verify current module availability and compatibility before planning an expansion.
Why Buy the TC-6EX-R from Big Frog Supply?
This page identifies the exact six-station outdoor model and explains its expansion platform without implying that an upgrade module is included. Big Frog Supply also carries compatible Irritrol weather sensors, remote accessories, valves, solenoids, and repair parts for building or maintaining a Total Control-R system.
