Brand: Kichler | Manufacturer Model: 15066CBR | Big Frog Supply SKU: 15066CBR
Product Overview
The Kichler 15066CBR Louvered Down Rail Deck Light is a slim 12-volt fixture for illuminating deck posts, railings, patios, stairways, and other outdoor transition areas. Its louvered face directs light downward toward the nearby walking surface and helps shield the lamp from direct view. The narrow vertical profile fits posts and trim where a wider deck light would be difficult to position.
This Centennial Brass version uses a solid brass housing rather than the aluminum construction found on the 15066AZT and 15066WHT variants. Brass is often selected for outdoor projects where long-term material durability and a naturally evolving finish are priorities. The fixture operates on a compatible 9- to 15-volt landscape-lighting system and uses one T5 wedge-base lamp rated up to 6.5 watts. The lamp is not included. A 72-inch lead wire and stainless-steel mounting hardware support installation, while the transformer, cable, connectors, and other system components are sold separately.
Key Features
- Slim louvered post-and-rail deck light
- Downward-directed light helps reduce glare
- Solid brass housing with Centennial Brass finish
- Wet-rated outdoor fixture
- Designed for 9- to 15-volt landscape systems
- Uses one T5 wedge-base lamp up to 6.5 watts
- 72-inch lead wire
- Stainless-steel mounting hardware
- Lamp and transformer sold separately
Common Uses
- Deck and stair railings
- Patio and gazebo posts
- Outdoor steps and transition areas
- Low-level pathway and perimeter lighting
Technical Specifications
-
Operating voltage: 9–15 VAC
-
Nominal system voltage: 12 V
-
Lamp type: T5 wedge base
-
Maximum lamp wattage: 6.5 W
-
Lamp included: No
-
Housing material: Brass
-
Finish: Centennial Brass
-
Location rating: Wet
-
Lead wire: 72 inches
Dimensions
-
Height: 6 inches
-
Width: 1.5 inches
-
Length/depth: 1.5 inches
Installation Notes
Use only with a compatible low-voltage landscape transformer and outdoor wiring system. Confirm lamp fit, transformer capacity, cable length, voltage drop, mounting surface, and connection method before installation. Brass finishes may change in appearance over time when exposed outdoors.
Frequently Asked Questions
How does 15066CBR differ from the other 15066 models?
The 15066CBR uses a brass housing and Centennial Brass finish; the AZT and WHT models use aluminum housings.
Is the lamp included?
No. Select a compatible T5 wedge-base lamp within the 6.5-watt maximum.
Is this fixture suitable for exposed outdoor locations?
Yes. Kichler identifies the 15066CBR as wet rated when correctly installed.
Why Buy This Product from Big Frog Supply?
The 15066CBR is the brass version of Kichler’s narrow louvered deck light, making material and finish the key selection details. Big Frog Supply separates it from the aluminum variants and clearly identifies the exact housing, dimensions, lamp type, and outdoor rating.
