Kichler 16171CBR30 3000K LED Louvered Surface-Mount Step Light – Centennial Brass
Brand: Kichler | SKU: 16171CBR30
Product Overview
The Kichler 16171CBR30 is a 12V integrated LED step light for surface mounting on a deck, patio, or riser. The louvered face directs a modest pool of light down a step or walkway edge. At 7 lumens, it is an accent for finding the transition between levels rather than a broad area light. The Centennial Brass face remains a design detail by day; 3000K supplies clear warm-white light at night.
Key Features
- 7-lumen integrated LED in 3000K.
- Louvered surface-mount design in Centennial Brass.
- Wet rated and designed for installation without a junction box.
Common Uses
- Deck steps and stair risers
- Low-glare accents along a patio edge
Technical Specifications
- Model: 16171CBR30
- Light output: 7 lumens
- Color temperature: 3000K
- Integrated LED: 0.82W / 1.45VA
- Input: 12V landscape system; operating range 9–15V
- Rating: wet location; 2,000V surge protection
- Finish: Centennial Brass
Dimensions
- Height: 3.00 in.
- Length: 6.00 in.
- Width: 0.75 in.
Compatibility & Installation Notes
Surface mounting avoids a junction box. Kichler lists a diffuser, mounting hardware, template, wire connectors, and 84 in. of usable 18 AWG leads. Plan a compatible 12V transformer, cable route, and mounting surface according to the instructions.
FAQ
Does it need a separate bulb?
No. The LED light source is integrated.
Is a junction box required?
Kichler describes this surface-mount design as installing without a junction box; follow its wiring instructions.
Why Buy From Big Frog Supply
Big Frog Supply identifies the louvered design, 7-lumen output, 3000K color, and Centennial Brass finish so you can choose the intended step-light appearance.
Model: 16171CBR30
Louvered surface-mount step light
7 lumens; 3000K; integrated LED
0.82W / 1.45VA; 9–15V operating range on a 12V landscape system
Wet rated; 2,000V surge protection
Finish: Centennial Brass
Dimensions: 3.00 in. H x 6.00 in. L x 0.75 in. W
