EX17DTP is a quick, flexible installed, ductless, propane gas, direct vent wall furnace from Rinnai; the perfect supplemental or specific zone heating solution that seeks out cold spots and within seconds begins to gently heat the room or space for maximum comfort. WiFi enabled thermostat connection ready.
- Warranty 10 yrs on Heat Exchanger/ 5 years on Parts/ 2 Year on Labor
- 8,700 BTU / (2.4 kW) (minimum)
16,700 BTU / (4.9 kW) (maximum)
See how the Rinnai EnergySaver® Direct Vent can work for you.
With a Rinnai EnergySaver® Direct Vent Wall Furnace, you can be assured of consistent comfort and warmth. Designed to constantly monitor room temperature, Rinnai's unique modulating technology can respond immediately to even the smallest temperature fluctuations.
How It Works
- Constantly monitors room temperature 2"? (5 cm) from the floor
- Consistently detects temperature changes of less than 1° F
- Within seconds, the Rinnai EnergySaver® Direct Vent Wall Furnace begins to gently heat the room
- Fan speed and BTU output increase as necessary to reach the preset temperature
- As the room reaches the desired temperature, the EnergySaver® Direct Vent Wall Furnace reduces fan speed and BTU output
- In case of a sudden influx of cold air, the EnergySaver® Direct Vent Wall Furnace automatically adjusts fan speed and BTU to quickly restore warmth to the room.
Heat is distributed evenly and heat loss is minimized since Rinnai EnergySaver® Direct Vent Wall Furnaces require no ductwork.
USER-FRIENDLY CONTROL PANEL
Manage the temperature in your home with our user-friendly control panel. Simply choose a set temperature or customize heating during the day by programming the timers.
NEW Cabinet Design
NEW User Friendly Control
NEW Setback Features
Standby Power Less than 1 Watt
Temperature Setting in Celsius or Fahrenheit
Self-Diagnostic with Error Code Indicator
"Cool to the Touch" Cabinet
Child Safety Lock
7-State Modulating Gas Valve and Variable Speed Blower
Whisper Quiet Fan
10-Year Heat Exchanger Warranty, 5 Year Parts, 2 Years Labor
|Input Range (Low/High)
8,200 / 16,700 BTU
|Fan Output (Low/High)
111.3 / 141.5 CFM (3.2 / 4.0 CMM)
Width: 29.9 inches (760 mm)
Height: 22.9 inches (582 mm)
Depth: 10.1 inches (257 mm)
57 lbs (26 kg)
|Power Consumption (Electronic ignition)
|Standby Power Consumption
Less than 1 watt
33 - 38 dB
|Total Extended Vent
13 ft. (4 m)
|Total Vertical Vent
10 ft. (3 m)
10-year on heat exchanger, 5-year on parts, 2-year on labor
10,200 ft. (3,109 m)
*It is recommended that a trained and qualified professional who has attended a Rinnai training class complete the installation. The warranty may be voided due to any improper installation.
— Installation and service must be performed by a licensed professional.
