Rain Bird SXB360025 360° Full-Circle Xeri-Bubbler — 1/4-Inch Barb
Brand: Rain Bird | SKU: SXB360025
Product Overview
The Rain Bird SXB360025 directs 8 low-volume streams in a full-circle (360°) pattern. Turn the outer cap to adjust flow and coverage around shrubs, trees, containers or flower beds. This version has a 1/4-inch barb inlet for compatible distribution tubing.
Key Features
- 360° full-circle pattern with 8 streams.
- Outer-cap adjustment changes flow and wetted coverage.
- 1/4-inch barb inlet for compatible distribution tubing.
- Cap unscrews from the base for cleaning.
- Operates at 15–30 psi.
Common Uses
- Targeted watering around shrubs, trees and container plantings.
- Watering around a central point where full-circle coverage suits the layout.
Technical Specifications
- Model: SXB360025 / SXB-360-025; manufacturer part X64036.
- Pattern: 360° full-circle; 8 streams.
- Connection: 1/4-inch barb inlet.
- Operating pressure: 15–30 psi.
- Adjustable flow: 0–13 GPH at 30 psi; 0–8.5 GPH at 15 psi.
- Maximum flow and coverage depend on inlet pressure and cap setting.
- Bubbler head only; tubing, connector and stake are separate components.
- Separate 10-32 threaded and spike-mounted versions are available.
Dimensions
The 1/4-inch designation describes the barb connection, not the bubbler’s overall dimensions. Leave clearance to turn and remove the cap, and position the outlet above soil and mulch so the streams remain unobstructed.
Compatibility & Installation Notes
Connect the barb inlet to compatible 1/4-inch distribution tubing and support the head with a suitable stake when required. The manufacturer’s installation detail shows a barb-inlet Xeri-Bubbler on a tubing stake, supplied from polyethylene tubing through a separate connector. It is an installation example, not a complete kit. Flush the supply, use appropriate upstream filtration and regulate pressure to 15–30 psi. Turn the cap to set the flow and coverage, then inspect the wetted area for runoff. This adjustable bubbler’s flow varies with pressure; it does not provide a fixed pressure-compensated GPH rating. Secure the tubing because a dislodged bubbler can release unregulated flow. Unscrew the cap from the base when cleaning is needed.
Frequently Asked Questions
What pattern does SXB360025 produce?
It produces 8 streams in a full-circle (360°) pattern.
Is the flow fixed at 13 GPH?
No. The cap adjusts the flow, and maximum flow depends on pressure: up to 13 GPH at 30 psi or 8.5 GPH at 15 psi.
Is a stake included with this version?
This is the 1/4-inch barb-inlet bubbler head. Tubing, connectors and a supporting stake are separate components; the spike-mounted model is a different version.
Why Buy from Big Frog Supply?
Choose SXB360025 when a central watering point needs eight streams around a full circle. Its 1/4-inch barb suits compatible distribution tubing, and cap adjustment lets you tune flow and coverage together. Plan for up to 13 GPH at 30 psi when fully open, then adjust to the planting area and soil absorption.
Model: SXB360025 / SXB-360-025
Manufacturer part: X64036
Pattern: 360° full-circle
Streams: 8
Inlet: 1/4-inch barb
Operating pressure: 15–30 psi
Adjustable flow: 0–13 GPH at 30 psi; 0–8.5 GPH at 15 psi
Maximum flow and coverage vary with pressure and cap setting
Outer cap adjusts flow and coverage; removes for cleaning
Bubbler head only; tubing, connector and stake separate
Not the 10-32 threaded or spike-mounted version
