Rain Bird XS360TS 360° True Spray Micro-Spray — 10-32 Thread
Brand: Rain Bird | SKU: XS360TS
Product Overview
The Rain Bird XS360TS applies a full-circle fan spray for ground cover, flower beds and container plantings. Turn the outer cap to adjust flow and wetted coverage. This version uses a 10-32 threaded inlet; choose the connection to match the riser or tubing in the watering layout.
Key Features
- Full-circle fan spray pattern.
- Outer cap adjusts flow and wetted radius.
- 10-32 threaded inlet.
- Cap fully unscrews from the base for cleaning.
- Operates at 15–30 psi.
Common Uses
- Watering ground cover, mass plantings and annual flower beds.
- Full-circle watering around containers or a central point in a planting bed.
Technical Specifications
- Model: XS360TS; manufacturer part X66030.
- Pattern: 360° full-circle fan spray.
- Inlet: 10-32 threaded.
- Operating pressure: 15–30 psi.
- Adjustable flow: 0–24.5 GPH at 30 psi; 0–17 GPH at 15 psi.
- Published wetting radius: 0–6.7 feet; actual coverage varies with pressure and cap setting.
- Adjustment and cleaning: turn the outer cap to adjust; unscrew it completely to clean.
- Spray head only; riser or tubing, stake, manifold, filter and regulator are separate components.
Dimensions
The 10-32 designation describes the inlet thread, not the head’s overall dimensions. The 6.7-foot figure is wetting radius. Leave clearance to turn and remove the cap, and position the outlet above soil, mulch and nearby obstructions.
Compatibility & Installation Notes
Thread the inlet into a compatible 10-32 riser or adapter. The manufacturer’s installation detail shows this threaded True Spray head on a PolyFlex riser and adapter connected to a PVC tee. The drawing is an installation example; illustrated supply and mounting parts are separate. Flush the supply, provide appropriate upstream filtration and regulate pressure to 15–30 psi. Turn the cap to set flow and coverage, then inspect the wetted area for runoff and missed areas. Flow changes with pressure and cap setting; this is not a fixed-flow pressure-compensating emitter. Secure tubing connections, because a dislodged head can release unregulated water. Remove the cap from the base when cleaning is needed.
Frequently Asked Questions
Is the flow fixed at 24.5 GPH?
No. Flow is adjustable up to 24.5 GPH at 30 psi or 17 GPH at 15 psi, depending on cap setting.
What is the wetting pattern?
It produces a full-circle fan spray with a published adjustable radius of 0–6.7 feet. Actual coverage depends on pressure, setting and site conditions.
Which inlet does this version use?
XS360TS has a 10-32 threaded inlet. The 1/4-inch barb and spike-mounted versions are separate models.
Why Buy from Big Frog Supply?
Choose XS360TS for full-circle fan watering from a compatible 10-32 riser or adapter. Its cap adjusts flow and coverage together, with a published radius up to 6.7 feet. Check the 15–30 psi supply and allow for up to 24.5 GPH at 30 psi; this threaded head fits a different connection than the XS360TS025 barb version.
Model: XS360TS
Manufacturer part: X66030
360° full-circle fan spray
Inlet: 10-32 threaded
Operating pressure: 15–30 psi
Adjustable flow: 0–24.5 GPH at 30 psi; 0–17 GPH at 15 psi
Published wetting radius: 0–6.7 feet
Flow and coverage vary with pressure and cap setting
Outer cap adjusts flow and radius; fully removes for cleaning
Not a fixed-flow pressure-compensating emitter
Spray head only; mounting and supply components separate
