How to Install a Water-Powered Backup Sump Pump (Step-by-Step + Code Tips)
How to Install a Water-Powered Backup Sump Pump
When the power goes out—or your primary sump pump fails—a water-powered backup sump pump uses municipal water pressure to keep your pit under control. Below is a practical, code-friendly walkthrough to choose, install, and test one, plus links to proven models.
Before You Start (Prerequisites)
- Municipal water only: Water-powered units need city water pressure; a private well won’t run during outages.
- Pressure & piping: Most units operate ~20–100 PSI; performance improves with ~30+ PSI. Typical inlet is 3/4" and discharge integrates with 1-1/2" sump piping.
- Pit size: Ensure an 18"+ diameter pit so the backup float won’t interfere with the primary pump/float.
- Code/backflow: Many jurisdictions require a testable RPZ backflow preventer on the dedicated water supply to the backup. Always confirm local requirements.
How it works: A Venturi jet uses a small amount of potable water to move a larger volume from the sump (often around a 2:1 pump-out to water-use ratio depending on pressure and lift).
Plan Your Layout
- Mounting: Most units mount above the pit on the discharge line or on the pit wall where the float has clear travel.
- Water supply: Run a dedicated, full-port 3/4" cold-water line with required shutoffs, unions, and backflow protection per code.
- Discharge: Tie the backup into your 1-1/2" discharge with a union for service. Confirm check-valve orientation so water can’t recirculate.
Step-by-Step Installation
- Dry fit everything. Verify pit clearance, float travel, and discharge routing. Mark anchor points.
- Plumb the discharge. Cut into the 1-1/2" discharge line, install the backup per the flow arrow, and add a union for future service.
- Run the water line. From a reliable cold-water source, install a full-port shutoff, (code-required) backflow preventer, and any expansion/thermal relief parts your jurisdiction calls for, then connect to the pump’s 3/4" inlet.
- Secure the unit. Fasten per the manual so vibration won’t shift float position. Keep the body level.
- Leak-check. Slowly open the water shutoff and inspect every joint. With the pit wet, lift the backup float to trigger operation and observe discharge.
- Label & access. Tag the shutoff/backflow and leave clearance for annual testing.
Performance & Sizing Tips
- Know your inflow. During heavy rain, can the backup keep up with your pit inflow at your home’s water pressure and lift height?
- Check the chart. Look up your model’s GPM at your supply pressure and vertical lift. If you don’t know your peak inflow yet, first calculate your gallons per minute (GPM) using our simple formula & free calculator.
- Keep runs short. Minimize elbows/restrictions on both the water supply and discharge for best performance.
Maintenance & Testing
- Monthly test: Pour water into the pit until the backup float lifts; confirm a strong stream at the discharge.
- Backflow testing: If your area requires annual RPZ tests, schedule them to keep the system code-compliant.
- Inspect checks & unions: Make sure check valves seal and unions are drip-free after tests.
Shop:
Sump & Leak Alarms
Water-Powered Backup FAQs
Do I need city water for a water-powered backup?
Yes. These pumps rely on pressurized municipal water. A private well won’t help during a power outage unless your well pump is on backup power—and local code may still require a dedicated, protected supply.
How much water does it use?
Output depends on your inlet pressure and lift height, but a common rule of thumb is ~2 gallons pumped for every 1 gallon of city water used. Check your model’s performance chart for exact numbers.
Will it replace my primary electric sump pump?
No. It’s a backup that takes over during outages or primary failures. Keep a reliable primary pump installed and tested.
What backflow device do I need?
Many jurisdictions require a testable RPZ backflow preventer on the dedicated supply line to the backup pump. Always follow local code and arrange annual testing if required. Shop backflow assemblies.
What size pit do I need?
Plan for an 18" minimum diameter so the backup’s float doesn’t interfere with the primary pump or its float.
How do I know if the backup is big enough for my home?
Compare your model’s GPM at your water pressure and vertical lift with the pit’s peak inflow. If you don’t know your inflow, first calculate your gallons per minute (GPM).
Where should I connect the water line?
Use a dedicated 3/4" cold-water line with a full-port shutoff and the required backflow preventer. Keep runs short and minimize elbows/restrictions for best performance.
How loud is it?
You’ll typically hear a steady “hiss” of water through the Venturi while it runs and normal discharge noise. Adding a sump cover reduces sound.
What maintenance is required?
Monthly: Test by lifting the float (with water in the pit) to confirm a strong discharge and leak-free joints. Annually: If using an RPZ, schedule its required test. Inspect check valves and unions.
Can I install it myself?
Install rules vary. Many areas require a licensed plumber—especially when an RPZ is involved. Always follow the manufacturer’s instructions and local plumbing code.
Ready to choose a model? Shop water-powered backup sump pumps or add alerts with a sump alarm.
Code note: Installation and backflow device selection are jurisdiction-specific. Many areas require a licensed plumber and annual testing for RPZ assemblies. Always follow the manufacturer’s instructions.
