Spec Sheet Install Manual

Choosing the right Tankless Electric Water Heater for your home.

Features

  • Point-of-use heating eliminates long hot water pipe runs
  • Compact design - fits virtually anywhere
  • Hot or cold water feed
  • Adjustable temperature control 50-140°F
  • T&P valve included
  • Single weld glass lined tank for extended life
  • Floor mount or wall hung (bracket included)
  • Status indicator light
  • 120V cord provided for EMT1, EMT2.5, EMT 4
  • ETL listed to UL174 and NSF373

California P65 Warning

Specifications

Performance

  • GPM Turn On: N/A
  • Physical Max Volume: 0.0 gpm
  • Minimum Operating Temp: N/A
  • Max Operating Temp: 140
  • Minimum Operating Pressure: 25 PSI
  • Max Pressure Rating: 150 PSI

Electrical

  • Power: 1.4kW
  • Volts: 120V
  • Phase: Single
  • Amperage: 12
  • Recommended Wire Size: Plug-in

Physical

  • Height: 17 inches
  • Width: 11 inches
  • Depth: 11.5 inches
  • Weight: 20 lbs
  • Color: White
  • Element Type: Immersion
  • Element Material: Copper

Plumbing

  • Water Connection: 1/2''
  • NPT or Compression: NPT
  • Plumbing Configuration: Top
  • Hot or Cold Feed: Pre-heated or Cold water Inlet
  • Aerator Supplied: No
  • # of Aerators Supplied: N/A
  • GPM Flow Rate of Aerator Supplied: N/A

Performance

GPM Turn On: N/A
Physical Max Volume: 0.0 gpm
Minimum Operating Temp: N/A
Max Operating Temp: 140
Minimum Operating Pressure: 25 PSI
Max Pressure Rating: 150 PSI
Electrical

Power: 1.4kW
Volts: 120V
Phase: Single
Amperage: 12
Recommended Wire Size: Plug-in

Height: 17 inches
Width: 11 inches
Depth: 11.5 inches
Weight: 20 lbs
Color: White
Element Type: Immersion
Element Material: Copper
