Dauer Manufacturing - 490541 - 150W Stainless Steel Small Box Transformer

Spec Sheet

Stainless steel professional small box low-voltage 150-watt transformer. Four taps on DIN rail for 12- to 15-volt output. One common tap. 92 to 95% regulation. Highly efficient. Photocell plug, amp loop, and timer socket. 12.5-amp breaker. Removable hinged door. Lifetime warranty.

Specifications:

• Output:
• Wattage: 150W
• Amps:  12.5A
• Taps for:  12V, 13V, 14V, 15V. One common tap
• Input:
• Voltage:  120V
• Hertz:  60HZ
• Amps:  1.25A
• Housing:  Stainless steel housing and removable hinged swinging door with lockable latch.  Pre-punched bottom and side panels.
• Agency Listing:  ETL approved (5013561). Conforms to ANSI/UL 1838
• Warranty:  Lifetime
• Model:  T150EMSP

Features:

• DIN Rail
• Photocell receptacle
• Timer plug
• Primary amp loop
• 12.5A breaker
• Heavy-duty grounded 5-foot power cord
• Suitable for indoor and outdoor use

Dimensions:

• Height:  11.75"
• Width:  5.8"
• Depth:  5.5"
• Overall Height:  12.88"

Output:
Wattage: 150W
Amps: 12.5A
Taps for: 12V, 13V, 14V, 15V. One common tap
Input:
Voltage: 120V
Hertz: 60HZ
Amps: 1.25A
Housing: Stainless steel housing and removable hinged swinging door with lockable latch. Pre-punched bottom and side panels.
Agency Listing: ETL approved (5013561). Conforms to ANSI/UL 1838
Warranty: Lifetime
Features:

DIN Rail
Photocell receptacle
Timer plug
Primary amp loop
12.5A breaker
Heavy-duty grounded 5-foot power cord
Suitable for indoor and outdoor use

Height: 11.75"
Width: 5.8"
Depth: 5.5"
Overall Height: 12.88"
