Liberty LCU-SP220S Shallow Pan Condensate Pump — 230V with Safety Switch

Liberty Pumps LCU-SP220S Shallow Pan Condensate Pump

The Liberty LCU-SP220S is a shallow pan condensate pump built for international or commercial systems requiring 230V power. With its ultra-low 4.8" height, it fits into tight clearance applications under HVAC equipment. The pump includes a safety switch for overflow protection, a corrosion-resistant ABS tank, stainless steel shaft, and a removable check valve for serviceability. Capable of up to 20 ft lift, this pump ensures reliable condensate removal in demanding environments.

Key Features & Benefits

• Shallow Pan Profile — only 4.8" tall, designed for space-restricted installations.
• 230V Operation — compatible with high-voltage systems and international setups.
• Built-In Safety Switch — overflow protection for peace of mind.
• Durable ABS Tank & Stainless Shaft — rugged build for long-lasting use.
• Multiple Inlet Options — connect to A/C units, furnaces, or dehumidifiers.
• 3/8" Barbed/Threaded Discharge — flexible installation options.
• Removable Check Valve — easy maintenance and cleaning.

Specifications

LCU-SP220S
HP 1/30
Volt 230
Amps .7
Capacity 2 US Qt
Max Head 15'

6.5" Height
11-1/8" Length
5" Width
4.5 Lbs
