Rinnai Ultra Series Tankless Water Heaters deliver innovation and technological leadership in condensing tankless water heating design, while providing homeowners with an endless supply of hot water, energy savings, a space-saving design and environmental benefits. The NEW RUCS75i at 160,000 BTUs, available in natural gas and propane, offer condensing technology with lower to mid-range capacity at attractive price points. As the only manufacturer to offer both concentric and PVC/CPVC dual pipe venting options on the same unit, the RUCS models join the Ultra Series lineup of innovative designs and enduring values.
These new Rinnai RUCS/RUS Condensing Tankless Water Heaters expand Rinnai's Ultra Series condensing lineup to 6 models, in both indoor and outdoor versions, ranging from 130,000 to 199,000 BTU with efficiencies from .93 EF to .96 EF, providing the most complete condensing lineup in the industry.
Features
- ENERGY STAR® Qualified - Energy Factor up to .93
- The RUCS75i, with a maximum of 160,000 BTU, can deliver 7.5 GPM of continuous hot water
- Built-in status monitor; easily upgradable to MC-91-2 controller for remote operation
- Temperature Range of 120°F - 140°F, with four convenient pre-set temperatures
- Stylish white cabinet and matching cover panel
- Quiet Operation: RUCS75 @ 55dB
- High Altitude Approved up to 5,400 feet
- Ultra Low NOx Compliant
- Built-in freeze protection down to -22°F for indoor models and -4°F for outdoor models (gas/electricity required)
- Mobile Home Certified
- Fuel conversion kits available
Isolation Valves Sold Seperately
The Rinnai RUCS75iP requires isolation valves during installation. This valve kit includes hot and cold water shut-off valves, hot and cold water drain valves, and an ANSI approved pressure relief valve. Use of these valves will allow flushing of the heat exchanger and aid in servicing and troubleshooting of your Rinnai. You can purchase them with your water heater above or separately.
Specifications
| Dimensions |
Width: 18.5 inches (469.9 mm) |
| Height: 26 inches (660.4 mm) |
| Depth: 10 inches (254 mm) |
| Weight |
57.3 lbs (26 kg) |
| Installation Type |
Indoor |
| Minimum/Maximum BTU |
10,300 / 160,000 Natural Gas and Propane |
| Energy Factor |
0.93 for Natural Gas and Propane |
| Temperature Range |
Residential Only: 120°F - 140°F (49°C - 60°C) |
| Minimum Activation Rate |
0.4 gpm (1.5 lpm) |
| Flow Rate (70° / 50° Temperature Rise) |
4.2 / 5.9 gpm (15.9 / 22.3 lpm) |
| Hot Water Flow Rate Range |
0.26 - 7.5 gpm (0.98 - 28.4 lpm) |
| Controllers |
Standard: Status Monitor |
| Optional: MC-91-2US |
| Ultra Low NOx |
Yes |
| Warranty (Residential)* |
Limited 12-year on heat exchanger, 5-year on parts, 1-year on labor |
| Warranty (Commercial)* |
Residential Only |
| Mobile Home Certified |
Yes |
| Valves Shipped in Box |
No |
| High Altitude Approved |
Up to 5,400 ft. (1,646 m) |
| Certifications |
AHRI, CSA, Energy Star® |
| Venting Options |
Concentric or PVC / CPVC |
| Tankless Rack System (TRS/TRW) Compatible |
No |
| 1/2" Gas Line Compatible*** |
Yes |
Installation Type Indoor
Minimum/Maximum BTU 10,300 / 160,000 Natural Gas and Propane
Energy Factor 0.93 for Natural Gas and Propane
Temperature Range Residential Only: 120°F - 140°F (49°C - 60°C)
Minimum Activation Rate 0.4 gpm (1.5 lpm)
Flow Rate (70° / 50° Temperature Rise) 4.2 / 5.9 gpm (15.9 / 22.3 lpm)
Hot Water Flow Rate Range 0.26 - 7.5 gpm (0.98 - 28.4 lpm)
Controllers Standard: Status Monitor
Optional: MC-91-2US
Ultra Low NOx Yes
Warranty (Residential)* Limited 12-year on heat exchanger, 5-year on parts, 1-year on labor
Warranty (Commercial)* Residential Only
Mobile Home Certified Yes
Valves Shipped in Box No
High Altitude Approved Up to 5,400 ft. (1,646 m)
Certifications AHRI, CSA, Energy Star®
Venting Options Concentric or PVC / CPVC
Tankless Rack System (TRS/TRW) Compatible No
1/2" Gas Line Compatible*** Yes
